USED / NEW GE USM GO+

Request a Quote

USM Go+ NEW that takes field inspection NDT to the next level.
Light, handy and controlled by an intuitive arrow-keypad, it has the latest industrial electronics under the hood and offers excellent ultrasonic performances which allows for reliable detection of defects located just below the surface of the test piece.
USM GO+Small but mighty.
All you expect from an ultrasonic flaw detector, packed in a handheld.

Brand	GE
Catalog Number
Model Number	DMS GO +
Year of Manufacture	2019
Product Accessories	Display - 5 inch, 800 × 480 pixels, 108 × 64.8 mm (W x H), > 200 cd/m2 Size -(W x H x D) 175 × 111 × 50 mm (W × H × D) Weight- 850 g with battery Protection class IP 67 Operating temperature -10°C - 50°C Battery Li-Ion, rechargeable Power adapter / charger 100 – 240 V AC, 50/60 Hz Probe connector Dual Lemo-00 (T/R) PC interface Micro USB Memory card -SD-Card slot for all standard SD cards Reporting- Test report and A-Scan screen shot on SD-Card, Video recording of A-Scan Pulser- 120 – 300 V, 30 – 500 ns, flank < 10 ns, Spike, Square wave option -Puls Repetition Frequency 15 – 2000 Hz Damping- 50 and 1000 ohms Receiver 110 dB dynamic, 0.51 ~ 19.6 MHz analog bandwidth Filter BB 1-5 MHz, 2,25 MHz, 4 MHz, 5 MHz, 10 MHz, 13 MHz, 15 MHz Gates A and B independent, B triggered by A, C option Units mm, inch, μs Options AWS sizing tool (AWS D1.1), DAC 16 points according to EN 1712, EN 1713, EN 1714, ASTM E164, TCG 110 dB dynamic, DGS sizing tool according to EN 1712, EN 1713, EN 1714, ASTM E164, Data Logger, 3rd gate C, Square Wave Pulser Compliance-EN 55011,EN 61000-6-2: 2011, ISO 22232, ASTM E 1324, E317, ANSI/NCSL Z 540-1-1994, MIL-STD 45662A, MIL-STD 2154
