Over time, gear teeth are prone to surface cracking because of the constant torque they are submitted to. Surface-breaking cracks are typically found in the addendum, dedendum, and fillet of gear teeth, although they can also occur elsewhere.



• Gear module small: 13–20
• Casing is small.

• Topology long, single driver.

• Cable 3 m (9.8 ft).

• Coverage small: 50 mm (2.0 in).

• Central frequency 500 kHz.

• Frequency range 250 kHz–1 MHz.

• Coils (diameter × number) 4.5 mm × 22 (0.18 in × 22).

• Channels is 32.

• Minimum channel requirement 64.

• Minimum detectable crack length 5 mm (0.197 in).



The condition is brand new open box (BNOB)
